A Data Science Approach To Optimizing Internal Link Structure

Getting the internal linking optimized is important if you care about your site pages having enough authority to rank for their target keywords. By internal linking what we mean are pages on your website receiving links from other pages.

This is important because this is the basis by which Google and other searches compute the importance of the page relative to other pages on your website.

It also affects how likely a user would discover content on your site. Content discovery is the basis of the Google PageRank algorithm.

Today, we’re exploring a data-driven approach to improving the internal linking of a website for the purposes of more effective technical site SEO. That is to ensure the distribution of internal domain authority is optimized according to the site structure.

Improving Internal Link Structures With Data Science

Our data-driven approach will focus on just one aspect of optimizing the internal link architecture, which is to model the distribution of internal links by site depth and then target the pages that are lacking links for their particular site depth.

We start by importing the libraries and data, cleaning up the column names before previewing them:

import pandas as pd
import numpy as np
site_name = 'ON24'
site_filename = 'on24'
website = 'www.on24.com'

# import Crawl Data
crawl_data = pd.read_csv('data/'+ site_filename + '_crawl.csv')
crawl_data.columns = crawl_data.columns.str.replace(' ','_')
crawl_data.columns = crawl_data.columns.str.replace('.','')
crawl_data.columns = crawl_data.columns.str.replace('(','')
crawl_data.columns = crawl_data.columns.str.replace(')','')
crawl_data.columns = map(str.lower, crawl_data.columns)
print(crawl_data.shape)
print(crawl_data.dtypes)
Crawl_data

(8611, 104)

url                          object
base_url                     object
crawl_depth                  object
crawl_status                 object
host                         object
                             ...
redirect_type                object
redirect_url                 object
redirect_url_status          object
redirect_url_status_code     object
unnamed:_103                float64
Length: 104, dtype: object

The above shows a preview of the data imported from the Sitebulb desktop crawler application. There are over 8,000 rows and not all of them will be exclusive to the domain, as it will also include resource URLs and external outbound link URLs.

We also have over 100 columns that are superfluous to requirements, so some column selection will be required.

Before we get into that, however, we want to quickly see how many site levels there are:

crawl_depth
0             1
1            70
10            5
11            1
12            1
13            2
14            1
2           303
3           378
4           347
5           253
6           194
7            96
8            33
9            19
Not Set    2351
dtype: int64

So from the above, we can see that there are 14 site levels and most of these are not found in the site architecture, but in the XML sitemap.

You may notice that Pandas (the Python package for handling data) orders the site levels by digit.

That’s because the site levels are at this stage character strings as opposed to numeric. This will be adjusted in later code, as it will affect data visualization (‘viz’).

Now, we’ll filter rows and select columns.

# Filter for redirected and live links

redir_live_urls = crawl_data[['url', 'crawl_depth', 'http_status_code', 'indexable_status', 'no_internal_links_to_url', 'host', 'title']]
redir_live_urls = redir_live_urls.loc[redir_live_urls.http_status_code.str.startswith(('2'), na=False)]
redir_live_urls['crawl_depth'] = redir_live_urls['crawl_depth'].astype('category')
redir_live_urls['crawl_depth'] = redir_live_urls['crawl_depth'].cat.reorder_categories(['0', '1', '2', '3', '4',
                                                                                 '5', '6', '7', '8', '9',
                                                                                        '10', '11', '12', '13', '14',
                                                                                        'Not Set',
                                                                                       ])
redir_live_urls = redir_live_urls.loc[redir_live_urls.host == website]
del redir_live_urls['host']
print(redir_live_urls.shape)
Redir_live_urls

(4055, 6)

By filtering rows for indexable URLs and selecting the relevant columns we now have a more streamlined data frame (think Pandas version of a spreadsheet tab).

Exploring The Distribution Of Internal Links

Now we’re ready to data viz the data and get a feel of how the internal links are distributed overall and by site depth.

from plotnine import *
import matplotlib.pyplot as plt
pd.set_option('display.max_colwidth', None)
%matplotlib inline

# Distribution of internal links to URL by site level
ove_intlink_dist_plt = (ggplot(redir_live_urls, aes(x = 'no_internal_links_to_url')) +
                    geom_histogram(fill = 'blue', alpha = 0.6, bins = 7) +
                    labs(y = '# Internal Links to URL') +
                    theme_classic() +
                    theme(legend_position = 'none')
                   )

ove_intlink_dist_plt

From the above we can see overwhelmingly that most pages have no links, so improving the internal linking would be a significant opportunity to improve the SEO here.

Let’s get some stats at the site level.

crawl_depth
0             1
1            70
10            5
11            1
12            1
13            2
14            1
2           303
3           378
4           347
5           253
6           194
7            96
8            33
9            19
Not Set    2351
dtype: int64

The table above shows the rough distribution of internal links by site level, including the average (mean) and median (50% quantile).

This is along with the variation within the site level (std for standard deviation), which tells us how close to the average the pages are within the site level; i.e., how consistent the internal link distribution is with the average.

We can surmise from the above that the average by site-level, with the exception of the home page (crawl depth 0) and the first level pages (crawl depth 1), ranges from 0 to 4 per URL.

For a more visual approach:

# Distribution of internal links to URL by site level
intlink_dist_plt = (ggplot(redir_live_urls, aes(x = 'crawl_depth', y = 'no_internal_links_to_url')) +
                    geom_boxplot(fill = 'blue', alpha = 0.8) +
                    labs(y = '# Internal Links to URL', x = 'Site Level') +
                    theme_classic() +
                    theme(legend_position = 'none')
                   )

intlink_dist_plt.save(filename = 'images/1_intlink_dist_plt.png', height=5, width=5, units = 'in', dpi=1000)
intlink_dist_plt

The above plot confirms our earlier comments that the home page and the pages directly linked from it receive the lion’s share of the links.

With the scales as they are, we don’t have much of a view on the distribution of the lower levels. We’ll amend this by taking a logarithm of the y axis:

# Distribution of internal links to URL by site level
from mizani.formatters import comma_format

intlink_dist_plt = (ggplot(redir_live_urls, aes(x = 'crawl_depth', y = 'no_internal_links_to_url')) +
                    geom_boxplot(fill = 'blue', alpha = 0.8) +
                    labs(y = '# Internal Links to URL', x = 'Site Level') +
                    scale_y_log10(labels = comma_format()) +
                    theme_classic() +
                    theme(legend_position = 'none')
                   )

intlink_dist_plt.save(filename = 'images/1_log_intlink_dist_plt.png', height=5, width=5, units = 'in', dpi=1000)
intlink_dist_plt

The above shows the same distribution of the links with the logarithmic view, which helps us confirm the distribution averages for the lower levels. This is much easier to visualize.

Given the disparity between the first two site levels and the remaining site, this is indicative of a skewed distribution.

As a result, I will take a logarithm of the internal links, which will help normalize the distribution.

Now we have the normalized number of links, which we’ll visualize:

# Distribution of internal links to URL by site level
intlink_dist_plt = (ggplot(redir_live_urls, aes(x = 'crawl_depth', y = 'log_intlinks')) +
                    geom_boxplot(fill = 'blue', alpha = 0.8) +
                    labs(y = '# Log Internal Links to URL', x = 'Site Level') +
                    #scale_y_log10(labels = comma_format()) +
                    theme_classic() +
                    theme(legend_position = 'none')
                   )

intlink_dist_plt

From the above, the distribution looks a lot less skewed, as the boxes (interquartile ranges) have a more gradual step change from site level to the site level.

This sets us up nicely for analyzing the data before diagnosing which URLs are under-optimized from an internal link point of view.

Quantifying The Issues

The code below will calculate the lower 35th quantile (data science term for percentile) for each site depth.

# internal links in under/over indexing at site level
# count of URLs under indexed for internal link counts

quantiled_intlinks = redir_live_urls.groupby('crawl_depth').agg({'log_intlinks':
                                                                 [quantile_lower]}).reset_index()
quantiled_intlinks = quantiled_intlinks.rename(columns = {'crawl_depth_': 'crawl_depth',
                                                          'log_intlinks_quantile_lower': 'sd_intlink_lowqua'})
quantiled_intlinks

The above shows the calculations. The numbers are meaningless to an SEO practitioner at this stage, as they are arbitrary and for the purpose of providing a cut-off for under-linked URLs at each site level.

Now that we have the table, we’ll merge these with the main data set to work out whether the URL row by row is under-linked or not.

# join quantiles to main df and then count
redir_live_urls_underidx = redir_live_urls.merge(quantiled_intlinks, on = 'crawl_depth', how = 'left')

redir_live_urls_underidx['sd_int_uidx'] = redir_live_urls_underidx.apply(sd_intlinkscount_underover, axis=1)
redir_live_urls_underidx['sd_int_uidx'] = np.where(redir_live_urls_underidx['crawl_depth'] == 'Not Set', 1,
                                                   redir_live_urls_underidx['sd_int_uidx'])

redir_live_urls_underidx

Now we have a data frame with each URL marked as under-linked under the ‘’sd_int_uidx’ column as a 1.

This puts us in a position to sum the amount of under-linked site pages by site depth:

# Summarise int_udx by site level
intlinks_agged = redir_live_urls_underidx.groupby('crawl_depth').agg({'sd_int_uidx': ['sum', 'count']}).reset_index()
intlinks_agged = intlinks_agged.rename(columns = {'crawl_depth_': 'crawl_depth'})
intlinks_agged['sd_uidx_prop'] = intlinks_agged.sd_int_uidx_sum / intlinks_agged.sd_int_uidx_count * 100
print(intlinks_agged)

  crawl_depth  sd_int_uidx_sum  sd_int_uidx_count  sd_uidx_prop
0            0                0                  1      0.000000
1            1               41                 70     58.571429
2            2               66                303     21.782178
3            3              110                378     29.100529
4            4              109                347     31.412104
5            5               68                253     26.877470
6            6               63                194     32.474227
7            7                9                 96      9.375000
8            8                6                 33     18.181818
9            9                6                 19     31.578947
10          10                0                  5      0.000000
11          11                0                  1      0.000000
12          12                0                  1      0.000000
13          13                0                  2      0.000000
14          14                0                  1      0.000000
15     Not Set             2351               2351    100.000000

We now see that despite the site depth 1 page having a higher than average number of links per URL, there are still 41 pages that are under-linked.

To be more visual:

# plot the table
depth_uidx_plt = (ggplot(intlinks_agged, aes(x = 'crawl_depth', y = 'sd_int_uidx_sum')) +
                    geom_bar(stat = 'identity', fill = 'blue', alpha = 0.8) +
                    labs(y = '# Under Linked URLs', x = 'Site Level') +
                    scale_y_log10() +
                    theme_classic() +
                    theme(legend_position = 'none')
                   )

depth_uidx_plt.save(filename = 'images/1_depth_uidx_plt.png', height=5, width=5, units = 'in', dpi=1000)
depth_uidx_plt

With the exception of the XML sitemap URLs, the distribution of under-linked URLs looks normal as indicated by the near bell shape. Most of the under-linked URLs are in site levels 3 and 4.

Exporting The List Of Under-Linked URLs

Now that we have a grip on the under-linked URLs by site level, we can export the data and come up with creative solutions to bridge the gaps in site depth as shown below.

# data dump of under performing backlinks
underlinked_urls = redir_live_urls_underidx.loc[redir_live_urls_underidx.sd_int_uidx == 1]
underlinked_urls = underlinked_urls.sort_values(['crawl_depth', 'no_internal_links_to_url'])
underlinked_urls.to_csv('exports/underlinked_urls.csv')
underlinked_urls

Other Data Science Techniques For Internal Linking

We briefly covered the motivation for improving a site’s internal links before exploring how internal links are distributed across the site by site level.

Then we proceeded to quantify the extent of the under-linking issue both numerically and visually before exporting the results for recommendations.

Naturally, site-level is just one aspect of internal links that can be explored and analyzed statistically.

Other aspects that could apply data science techniques to internal links include and obviously are not limited to:

• Offsite page-level authority.
• Anchor text relevance.
• Search intent.
• Search user journey.

What aspects would you like to see covered?

Please leave a comment below.
